ROBOT INTELLIGENT CONTROLLER KITSEntry
Newrick
AI & IoT compatible controller
- 1-year warranty
- Built on PRAN
01 · OVERVIEW
The entry controller in the RICK series, for lab, education and research. Dual-controller architecture with ESP32 and Raspberry Pi Pico, built for engineering colleges, research labs, robotics educators and developers working on AI and IoT.
Ideal forEngineering colleges, students, research labs, robotics educators and developers, AI and IoT research labs and training.
Coursework
Control and connectivity
Motor control, PID tuning and sensor integration; networking with MQTT, HTTP, BLE and WiFi.
Research
Fusion, planning and edge AI
Sensor fusion, trajectory planning, obstacle avoidance; TinyML inference, edge analytics and vision; secure IoT communication and OTA updates.
Projects
Robots with a purpose
Autonomous delivery, warehouse logistics, smart agriculture, disaster response, healthcare robotics, swarm systems, AI service robots.
02 · KEY FEATURES
What Newrick does.
Dual controller
ESP32 and Raspberry Pi Pico.
Built-in 4-channel motor driver
Encoder support, 7–24V, 6A per channel.
Built-in IMU
Built-in mic and speaker
For voice projects.
12V 5000mAh battery with BMS
Fast charger included.
5V 4A USB output
Powers a single-board computer.
Expansion
USB, GPIO, I2C, UART, SPI and CSI camera.
Works with Jetson and Raspberry Pi
Single-board computers.
Protection
Short-circuit, thermal and reverse-polarity.
03 · SOFTWARE AND AI
Software and AI capabilities.
Languages
MicroPython, Rust, Arduino.
IDE support
Arduino IDE, VS Code, Thonny.
Cloud platforms
Blynk, ThingSpeak, ThingsBoard, Adafruit IO, Firebase.
Web interface
Browser-based, via local IP.
04 · TECHNICAL SPECIFICATIONS
Full specifications.
Computing unit
- Dual controller
- ESP32 and Raspberry Pi Pico
- Motor driver
- 4-channel with encoder support, 7V–24V, 6A per channel
- Connectivity
- WiFi, Bluetooth
- Memory
- 8GB standard, extendable
- Expansion
- USB, GPIO, I2C, UART, SPI, CSI
- Compatible SBCs
- Jetson series, Raspberry Pi series, others
Power system
- Battery
- 12V 5000mAh Li-ion with BMS protection
- Charging
- Fast charger included, with charging indicator
- Protection
- Short-circuit, thermal, reverse polarity
- Includes
- 5V 4A USB output, mic and speaker, IMU, battery indicator
Mechanical
- Weight
- Approx. 1kg
In the box
- Newrick unit, fully assembled
- Pre-flashed firmware
- 12V 5000mAh battery and fast charger
- User guide and setup documentation
- Curriculum access with purchase
- Project development videos
Optional add-ons
Sensor suite
- Flame
- Ultrasonic
- Heart rate
- Motion
- IR
- Smoke
- DHT11
- Rain
- Soil moisture
- DS18B20
- LDR
- RFID
- Touch
Actuators
- 12V water pump
- Vibration motor
- Solenoid lock
- Metal gear servo
06 · REQUEST A QUOTE
Request a quote for Newrick.
Tell us the quantity you need. We respond within 48 working hours.
Datasheet[SUPPLY]Corrected datasheet PDF
Quoting several products? Use the quote cart →
